The 50D was launched in August 2008 and was quite a jump from the 10.1MP of the 40D.
After waiting years for an update of the 30D, the 40D only lasted a year as top of the XXD range.
The rear screen is also of a much higher resolution than its predecessor.
Now superceded by EOS 60D – which, unlike the 50D, lacks AF microadjustment.
May 2013 – Video?
- 15.1 Megapixel APS-C CMOS sensor
- 6.3fps continuous shooting, max. burst 90 JPEGs with UDMA card
- ISO 100-3200, expandable to 12800
- 9-point wide area AF
- 3.0” Clear View VGA LCD with Live View mode & Face Detection Live AF
- Magnesium alloy body, with environmental protection
- EOS Integrated Cleaning System
- HDMI connection
- Full Specifications
- Euro Press release
- Canon EU 50D info
- US Press release
- 30D/40D specs comparison
- 40D/50D specs comparison
- Lens AF Microadjustment (for free)
- Video (YT) – Birds…
- 50D sample gallery [DPR]
- Sample Images [DD]
- More samples CL / FLKR / IR
- Reviews – CameraLabs / RL / OBP / PBG
- Reviews DPReview 50D review / Older ‘Hands on’ version
- Reviews Imaging Resource / TDP / Bob Atkins / DPS / Steves Digicams
- Reviews DCI / PhotoReview / Cnet / DPI
- User reviews at FM / Harold Merklinger article [LL]
- Suggested settings for Bird Photography
6th More insights about what’s in the 50D at C5D
27th Magic lantern software offers the chance to shoot video [EHD] and good video quality too…
17th Firmware Version 1.0.9 incorporates the following changes. 1. Optimises the camera’s performance when using certain UDMA 7-compatible CF cards released in February 2012 or later. 2. Corrects wording in the Dutch language menu screen
30th New Firmware to V1.0.8
Changes Firmware Version 1.0.8 incorporates the following improvements and fixes.
1. Improves the writing/reading speeds when using UDMA 7-compatible CF cards.
2. Fixes incorrect indications in the Simplified Chinese, Traditional Chinese, Arabic, Swedish, Spanish, Portuguese,
5th A series of 50D ‘instant’ rebates (in the US) running until June 5th
50D Body Only: $100
50D + 28-135 IS: $100
50D + 70-300 IS: $250
50D + 28-135 IS & 70-300 IS: $250
30th New firmware 1.0.7
Firmware Version 1.0.7 incorporates the following changes.
Corrects a phenomenon where captured images may tend to appear somewhat magenta depending on the shooting scene.
Fixes incorrect indications on the Arabic, Romanian, Spanish, and Ukrainian menu screens.
19th There have been numerous comments about aspects of 50D AF performance, and it appears (from an article in a Japanese magazine) that althought the AF sensor is different, it uses developments in the 1D3 AF algorithms, developed after the 1D3 launch.
22nd A cashback scheme for the 50D in Japan. Most likely to move inventory, rather than suggest that a replacement is close.
24th Some suggestions [DPR] that the firmware does indeed help with general image quality.
23rd Firmware update to V 1.0.6
Firmware Version 1.0.6 incorporates the following improvements and fixes.
Supports the AF assist beam feature of the new flash, Speedlite 270 EX, which is scheduled to be released in April 2009.
Changes the error indications that are displayed on the camera.
Addresses the vertical banding noise phenomenon.
Firmware Version 1.0.6 is for cameras with firmware up to Version 1.0.5. If the camera’s firmware is already Version 1.0.6, it is not necessary to update the firmware.
In addition, Firmware Version 1.0.5 has already been incorporated with improvements to support the AF assist beam feature of Speedlite 270 EX and change the error indications that are displayed on the camera.
When updating to Firmware Version 1.0.6, please also update the Digital Photo Professional, Picture Style Editor, ZoomBrowser EX, and ImageBrowser software to the following versions or later. For details, please refer to the Firmware Q&A section.
Digital Photo Professional : Version 3.5.2 (Windows/Macintosh)
Picture Style Editor : Version 1.4.2 (Windows/Macintosh)
ZoomBrowser EX : Version 6.2.1c (Windows)
ImageBrowser : Version 6.2.1c (Macintosh)
15th A firmware update could be on its way. A recently repaired 50D was returned with V1.0.6 installed [DPR]. See also 2nd mention at DPR.
3rd New review [DPI] added above
1st An interesting article with suggested Bird photography settings from Arthur Morris, also some of his shots of an Osprey showing good AF.
> Article link added above.
12th An interesting comment from Arthur Morris on 50D AF performance for bird photography – see discussion thread at [DPR]
Buy a lens and flash with your 50D and get a $200 rebate (US – until 1st March) – details on main Canon infopage
13th Despite rising prices for a number of camera products, the 50D price in the UK is still slipping (~£790 body)
31st HM article added above – I’ve always been interested to hear Harold’s thoughts on digital technologies. His articles on the view camera (tilt and shift) and depth of field are well worth reading.
22nd DPS review added above
20th Some interesting AF comments [BPN] and I notice that the UK price is still falling (£790 b/o) despite the state of the UK Pound…
18th There are more reports of third party flashes not working with the 50D and 5D2 – Sigma and SunPak are saying there will be firmware updates available to fix this for some models.
17th White paper link added above.
9th I was reminded that the new DPP update includes Auto Lighting Optimizer and Lens Aberration Correction.
I’ve added some updates to the reviews above.
17th Canon has released a version of DPP (V3.5.1) that supports the 5D Mk2 and amongst other things, supports luminance noise reduction for sRAW images taken with the EOS 5D Mark II and EOS 50D.
At the moment it only appears if you select a windows OS [Canon] – we’ll look for better download links…
30th DPR have a full review
28th New firmware (V1.0.3) amongst other things, fixes a 50D “Err 99” problem.
18th More updates to our info list above
6th We’ve added a link to a PDF of the user manual above
2nd The ‘Face Detect’ Video mentioned above has gone – if anyone sees it anywhere else, please do let us know?
30th Roland Lim just sent us his comprehensive review of the 50D. As ever Roland concentrates more on what the camera is like to use rather than the more technical DPR format.
20th Some UK dealers are suggesting that they already have stock of the 50D, and early deliveries are expected this weekend.
It looks though as if the first deliveries are largely kits, with body only packs being somewhat delayed.
US delivery seems somewhat later with at least one report saying 6th October (seems a long Delay?)
15th That new lens looks more like a 24mm (see lens page)
Meanwhile, the UK 50D body only price has dropped to £949
3rd – Want a good ‘standard’ lens for those 15MP? Looks like a new 35L lens before long.
2nd Price dropping already? I hear from Norway (thanks) that the 50D price advertised, has dropped since introduction [NOK ~12,600 to ~10,000] – given D90 pricing we may yet see some movement on this before the usual two month drop?
1st Samples added above.
30th Video links added above
28th There has been quite a bit of discussion about the AF functionality of the 50D – so far mostly speculation since no-one has had a production camera to test ;-)
Whilst the basic AF system is similar to the 40D, the additional processing power of the Digic IV processor makes it quicker to respond. The addition of AF Microadjustment is well received.
The AF functionality in liveview mode makes use of this power in the face recognition AF option. If I see any detailed tests of AF functionality, I’ll add them to the links and info section at the top of the page.
If you’re curious, you might like to look at our info on Canon future developments published before the 40D last August – it’s at the bottom of this page
27th We’ve just posted a collection of Canon technical info we received, on the 5D2 page.
Concerning the ‘early’ release of the 50D, have a look too at yesterday’s 5D2 info update
As widely expected, Nikon have announced the D90. The biggest update is probably video (720p) – there is a hands on review at DPR
26th 50D Official announcement
No real surprises there. Widely leaked, so that everyone was expecting it.
I’ve seen it priced at 1300 euro (Germany), NOK 12599 (Norway) or in ‘rip-off’ Britain £1200, or according to the US price below $1400 – guess we’ll be seeing a lot of people picking up one in the US when visiting ;-) Thanks everyone for sending in price info!
PDN has a good interview with Chuck Westfield including:
‘Calling the 50D the “big brother” to the 10.1 MP 40D which was released just over a year ago, Westfall said the older camera would remain on shelves until the end of the year for a list price of $1099, body only.
The 50D, which will be available in early October, will sell for $1399 body only, or as a kit with a new 18-200mm IS lens for $1599
Westfall said one of the keys about the 50D is its enhanced noise reduction which is “a stop to a stop and half better than the 40D.”
“Despite the fact that the pixels are smaller and one camera has a 10.1 MP sensor and the other has a 15.1 MP sensor, you’d think you’d have more noise but you have less,” he said. “The end result is better image quality all around which allows us to extend the ISO range to 12800.
The 50D is able to achieve this because of new “gapless microlenses” on the image sensor which capture more light and generate less noise.
“It’s the further evolution of a concept we’ve already explored. It’s gotten to the point where the microlenses are totally gapless and larger which produces the best efficency on a per pixel basis.
Consequently the light senstiviy portion of the pixel has increased while the non-light sensitive protion of the pixel has been shrunk down,” he said.
“Another part of the reason you have a cleaner signal coming out is DIGIC 4 is considerable more powerful than the DIGIC 3 and offers better noise reduction.”
With much discussion over Canon’s AF performance, expect this to be hotly debated as the camera (and anything else with Digic IV) appears.
What’s more, the universally derided ‘Print Button’ finally has another use!
AF Microadjustment is now available (we have an article on an easy way to carry it out)
– More info to follow as we get it. A big thanks to all who sent in info! –
|Amstelveen, The Netherlands, 26 August 2008: Canon today strengthens its EOS range with the addition of a powerful new digital SLR: the EOS 50D. With a 15.1 Megapixel CMOS sensor, 6.3 frames per second shooting and Canon’s latest DIGIC 4 image processor, the EOS 50D delivers unparalleled speed and resolution at a price point that is unique in today’s market.Outstanding, clean images
A newly designed 15.1 Megapixel CMOS sensor delivers ultra-detailed, low-noise images – ideal for large-scale reproduction or creative cropping. New manufacturing processes, plus redesigned photo diodes and microlenses, extend the light gathering capabilities of the sensor – allowing more pixels to be fitted on the CMOS sensor without compromising image quality. These changes ensure improved high ISO performance and low noise. High-speed, low light shooting is enabled by ISO levels of 3200, expandable to an ultra-sensitive 12800.
The EOS Integrated Cleaning System – including the improved Self Cleaning Sensor Unit with a new fluorine coating – increases protection of image quality by helping to reduce, repel and remove unwanted dust from the sensor. Stubborn particles can be removed automatically in post-production with Dust Delete Data and Canon’s included Digital Photo Professional software.
Canon’s new DIGIC 4 processor is fast enough to allow up to 6.3fps continuous shooting, in bursts of up to 90 JPEGs with a UDMA card. Used with Canon’s wide area AF system, which locks onto subjects with 9 individual cross type sensors, stunning action sequences can be captured – even in low-light conditions. This makes the EOS 50D particularly suited to sports and wildlife shooting.
DIGIC 4 works with the CMOS sensor to deliver 14-bit image processing, for smooth gradation and natural-looking colours – as well as ensuring ultra-fast startup times and near-instant image review after shooting.
A new 3.0” Clear View VGA LCD provides extra-large and wide angle-of-view image review, with plenty of clarity for accurate focus checks in playback. By switching to Live View mode – which displays a real-time image on the LCD – photographers can enjoy simplified shooting from awkward angles, or connect to a PC for remote shooting. Live Mode now offers three ways to auto focus: Quick AF, Live AF, and new Face Detection Live AF, which optimizes focus based on faces detected in the frame – for fast, spontaneous portraiture.
Control and ease
The famously intuitive EOS menu system includes a new Quick Control screen, for instant access to the most commonly-changed settings. A new Creative Auto mode offers automatic focus and exposure – while still allowing creative ‘tweaks’ to settings such as background sharpness.
“For advanced amateurs and semi-professionals – or professionals looking for a powerful backup model – the EOS 50D stands alone,” said Mogens Jensen, Head of Canon Consumer Imaging, Europe. “No other camera in this price bracket offers a comparable combination of speed and image quality.”
Canon’s CMOS technology is one of the company’s key competitive advantages, with noise reduction circuitry at each pixel site delivering virtually noise-free images. In comparison with CCD technology, the lower power consumption characteristics of Canon’s CMOS sensors also contribute to longer battery life.
Signal conversion in Canon’s CMOS sensors is handled by individual amplifiers at each pixel site. Unnecessary charge transfer operations are avoided, vastly speeding up the process of getting signal to the image processor. Noise generation is reduced, power consumption is limited and faster frame rate potential is increased.
Image data captured by the CMOS sensor is processed by Canon’s purpose-built DIGIC image processors before being written to the camera’s memory card. DIGIC technology uses advanced image processing algorithms to ensure precise, natural colours, accurate white balance, and advanced noise reduction. Ultra-fast processing speeds result in highly responsive camera operation and near-instant start-up times.
DIGIC chips work with a high speed DDR-SDRAM image buffer – reading, processing, compressing and writing image data fast enough to keep the buffer clear during long continuous shooting bursts. And because DIGIC integrates all key processing functions, power consumption is kept to a minimum.
EOS Integrated Cleaning System
The EOS Integrated Cleaning System combats sensor dust in three important ways: Reduce, Repel and Remove.
Reduce – Internal camera mechanisms are designed to minimise dust generation. The redesigned body cap prevents dust generation through wear on the cap itself.
Repel – Anti-static technologies, including a special fluorine coating, are applied to the low-pass filter covering the front of the sensor so as not to attract dust.
Remove – A Self-Cleaning Sensor Unit uses hi-frequency vibrations to shake dust from the infrared filter for a period of approximately one second after each start up. For instant shooting after power up, this feature is disabled immediately the shutter release is depressed.
Canon has also developed an internal Dust Delete Data system, which can map the position of visible dust on the sensor. This can then be deleted automatically after the shoot with the latest Digital Photo Professional software.
Picture Style pre-sets simplify in-camera control over image qualities. Picture Style pre-sets can be likened to different film types – each one offering a different colour response. Within each selectable pre-set, photographers have control over sharpness, contrast, colour tone and saturation. The camera’s factory default configuration is set to deliver immediately-usable JPEG images without need for additional menu settings. Picture Style presets applied to a RAW image can be revised with Canon’s Digital Photo Professional software.
The six pre-sets are:
Standard – for crisp, vivid images that don’t require post-processing
Portrait – optimises colour tone and saturation and weakens sharpening to achieve attractive skin tones
Landscape – for punchier greens and blues with stronger sharpening to give a crisp edge to mountain, tree and building outlines
Neutral – ideal for post-processing
Faithful – adjusts colour to match the subject colour when shot under a colour temperature of 5200K
Monochrome – for black and white shooting with a range of filter effects (yellow, orange, red and green) and toning effects (sepia, blue, purple and green).
Digital Photo Professional Software
Digital Photo Professional software provides high speed, high quality processing of lossless RAW images. Processing with Digital Photo Professional allows real-time display and immediate application of image adjustments, giving control over RAW image variables such as white balance, dynamic range, exposure compensation, noise reduction and colour tone – plus the ability to view Auto Focus points on an image. The Lens Aberration correction tool allows precise correction of different types of distortion caused by certain cameras. Images can be recorded in camera with sRGB or Adobe RGB colour space.
Digital Photo Professional supports sRGB, Adobe RGB, colourMatch RGB, Apple RGB and Wide Gamut RGB colour spaces. ICC (International Colour Consortium) profiles can be attached to TIFF or JPEG images when converted from RAW. This allows faithful reproduction of colours in software applications that support ICC profiles, such as Adobe Photoshop. For improved efficiency, a set of image adjustments can be saved as a recipe and applied.
The latest version of EOS Utility provides essential support for Live View remote shooting, camera configuration and image transfers. Tightly integrated with Digital Photo Professional, EOS Utility can be configured to monitor ‘hot’ folders, automatically renaming and moving incoming images to a structured file system. Users can also tag their images with EXIF data, including copyright information.
Picture Style Editor
Picture Style Editor allows users to create individual Picture Styles that fit with their personal requirements. Each Picture Style contains detailed information on how specific colours should be represented within an image. Once new Picture Styles have been created, they can be uploaded directly into the camera and applied to JPEG or RAW images. When working with RAW files in DPP, both personal Picture Styles and the 6 predetermined Picture Styles can all be adjusted.
|CANON U.S.A. STIMULATES THE CREATIVITY OF EXPERIENCED PHOTOGRAPHERS WITH THE INTRODUCTION OF THE NEW EOS 50D DIGITAL SLR CAMERACanon’s New DIGIC 4 Image Processor Fuels the 15.1 Megapixel Resolution, Expanded ISO Range and Enhanced Noise Reduction of the New EOS 50D Digital SLR
LAKE SUCCESS, N.Y., August 26, 2008 – With the demand for digital SLR cameras reaching unprecedented levels, Canon U.S.A., Inc., a leader in digital imaging, is answering the call with the announcement of the next evolution in advanced amateur digital SLR photography, the EOS 50D Digital SLR Camera with 15.1 megapixel resolution and Canon’s new DIGIC 4 image processor. Designed to offer extraordinary quality and image control for the advanced photographer with a passion for the art, the Canon EOS 50D Digital SLR camera includes an expanded ISO range, improved noise reduction, and in-camera photo editing features. Canon has loaded the EOS 50D camera with a number of enhancements and some trickle-down technology from Canon’s professional Digital SLR cameras, as well as a new Creative Auto Mode (CA) that gives users more creative flexibility to make image setting adjustments conveniently without the need to be a photo expert.
Canon has built upon the success of the popular EOS 40D model – which will remain in Canon’s line – with the EOS 50D Digital SLR camera. Expected to be the camera body of choice for advanced amateur photographers this holiday season, the Canon EOS 50D Digital SLR camera carries over the EOS 40D’s 14-bit Analog-to-Digital conversion process for smooth tones, and also includes enhanced noise reduction, especially at higher ISO ranges which will help bring those romantic nighttime shots into greater focus and clarity. Capable of shooting 6.3 frames per second (fps), the EOS 50D Digital SLR camera is ideal for shooting everything from beautiful night landscapes to fast-action sports.
Improved Image Quality
The Canon EOS 50D camera provides ISO speeds from ISO 100 up to ISO 3200 in 1/3-stop increments, along with two high-speed settings – H1 and H2 – of ISO 6400 and ISO 12800, respectively. Along with a wide ISO range, Canon gives shooters more tools to help maximize clarity and colour. The EOS 50D Digital SLR camera offers multiple levels of noise reduction during high-speed shooting. Users can choose from one of four settings– Standard/Weak/Strong/None – to help reduce digital noise that can result from poor lighting conditions.
As part of the camera’s internal image processing, the Canon EOS 50D Digital SLR camera conducts peripheral illumination correction, which automatically evens brightness across the image field, making an image of a blue sky even toned throughout, a function previously accomplished through post-processing software on a personal computer. Thanks largely to the DIGIC 4 processor, this automatic adjustment can be made in-camera during shooting with JPEG images or corrected in post-photoshoot processing with RAW images through Canon’s Digital Photo Professional (DPP) software, which is supplied at no extra charge.
Helping to ensure each picture’s subject is clearly visible, Canon’s enhanced Auto Lighting Optimizer analyzes the brightness of subjects and automatically adjusts dark images so that they appear brighter, perfect for subjects in shade or in backlit situations. The Auto Lighting Optimizer on the EOS 50D Digital SLR camera has been updated not only to optimize images while they are being taken, but can also optimize images post-capture, during playback, to help ensure the subject of each image does not appear too dark. This is especially helpful when an amateur photographer uses the camera, because post-capture enhancement can help maximize image quality without the need of a computer.
A significant upgrade to the Canon EOS 50D camera is its large, clear 3.0-inch Clear View LCD screen which features 920,000 dot/VGA resolution, four times the pixel count of the EOS 40D camera’s screen, for better clarity and colour. To help show off those fantastic shots, the EOS 50D camera includes an HDMI (High-Definition Multimedia Interface) output to display crisp, clear images on a High-Definition TV. The EOS 50D recognizes the needs of today’s photographers, and the faster processing speed of the DIGIC 4 processor helps support UDMA cards for faster writing of image files.
The camera is also equipped with a high-performance viewfinder featuring 0.95x magnification and the same high-performance Autofocus (AF) system as the EOS 40D camera with nine cross-type sensors for accurate target subject acquisition with lenses possessing maximum apertures of f/5.6 or faster and a high-precision diagonal center cross-type AF point that’s effective with f/2.8 and faster lenses, helping photographers ensure better focus of their targets. The AF Microadjustment feature, originally introduced last year with the Canon EOS-1D Mark III professional digital SLR camera, has also been added to the EOS 50D for maximum control over focusing precision.
Canon Gets Creative For Advancing Amateurs
Better Live View
Two Small RAW Formats
EOS Integrated Cleaning System
Pricing and Availability
New EF-S 18-200mm f/3.5-5.6 IS Lens
More info to follow, as we find it
|Sensor||22.3 x 14.9 mm CMOS sensor
RGB colour Filter Array
Built-in fixed low-pass filter (with self-cleaning unit)
15.5 million total pixels
15.1 million effective pixels
3:2 aspect ratio
|Image processor||DIGIC 4|
|A/D conversion||14 bit|
|Image sizes||4752 x 3168
3456 x 2304
2353 x 1568
|File formats||RAW (.CR2; 14-bit)
JPEG (EXIF 2.21) – Fine / Normal
RAW + JPEG (separate files)
sRAW1 (7.1 MP)
sRAW2 (3.8 MP)
|Lenses||Canon EF / EF-S lens mount
1.6x field of view crop
|Dust reduction||“EOS Integrated Cleaning System”
Self-cleaning sensor unit (filter in front of sensor vibrates at high frequency at start-up and shutdown – can be disabled)
Dust Delete Data – Data from a test shot is used to ‘map’ dust spots and can be later removed using Canon DPP Software
|Auto focus||9-point TTL CMOS sensor
All points cross-type for lenses of F5.6 or faster
Center point additionally sensitive with lenses of F2.8 or faster
AF working range: -0.5 – 18 EV (at 23°C, ISO 100)
|Focus modes||One shot AF
AI Servo AF
AI Focus AF
|AF point selection||Auto
|Predictive AF||Up to 8 m|
|AF assist||Stroboscopic flash|
|AF microadjust||+/- 20 steps
Adjust all lenses by same amount/individually adjust up to 20 lenses
|Metering||TTL 35 zone SPC
Metering range: EV 0.0 – 20 EV
|Metering modes||Evaluative 35 zone, Partial (9% at center), Spot metering (approx. 3.8% at center), Center-weighted average|
|AE lock||Auto: One Shot AF with evaluative metering
Manual: AE lock button
|Exposure compensation||+/-2.0 EV
0.3 or 0.5 EV increments
|Exposure bracketing||+/- 2.0 EV
0.3 or 0.5 EV increments
|Sensitivity||Auto ISO (100-1600)
ISO 100 – 3200
0.3 or 1.0 EV increments
H1 (6400) and H2 (12800) expansion
100,000 exposure durability
30 – 1/8000 sec
0.3 or 0.5 EV increments
Flash X-Sync: 1/250 sec
|Aperture values||F1.0 – F91
0.3 or 0.5 EV increments
Actual aperture range depends on lens used
|White balance||Auto, Daylight, Shade, Cloudy, Tungsten, Fluorescent, Flash, Custom, Kelvin (2500 – 10000 K in 100 K steps)|
|WB bracketing||+/-3 levels
Blue / Amber or Magenta / Green bias
|WB shift||Blue (-9) To Amber (+9)
Magenta (-9) to Green (+9)
|Picture style||Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User def. 1, User def. 2, User def. 3|
|Custom image parameters||Sharpness: 0 to 7
Contrast: -4 to +4
Saturation: -4 to +4
colour tone: -4 to +4
B&W filter: N, Ye, Or, R, G
B&W tone: N, S, B, P, G
|Image processing||Highlight tone priority
Auto lighting optimizer (4 settings)
Long exposure noise reduction
High ISO noise reduction (4 settings)
Auto correction of lens peripheral illumination (vignetting)
95% frame coverage
Magnification: 0.95x(-1 diopter with 50 mm lens at infinity)
Eyepoint: 22 mm
Interchangeable focusing screen Ef-A standard (2 other types optional)
Dioptric adjustment: -3.0 to +1.0 diopter
|Ef-A (Standard Precision Matte – included)
Ef-D (Precision Matte with grid)
Ef-S (Super Precision Matte for easier manual focus)
|Mirror||Quick-return half mirror (transmission:reflection ratio 40:60)
Mirror lock-up (once or multiple exposures)
|Viewfinder info||AF points, Focus confirmation light, ISO sensitivity, Shutter speed, Aperture, Manual exposure, AE Lock, Exposure compensation amount, AEB level, Spot metering area, Flash ready, Red-eye reduction lamp on, High-speed sync, FE Lock, Flash compensation amount, ISO speed (while changing), WB correction (while changing), Highlight tone priority icon *, B&W mode icon, Warnings, Maximum burst for continuous shooting, Buffer space|
|LCD monitor||3.0 ” TFT LCD
7 brightness levels
160 ° viewing angle
|LCD Live view||Live TTL display of scene from CMOS image sensor
100% frame coverage
Real-time evaluative metering using CMOS image sensor
Best view or exposure simulation
Grid optional (x2)
Magnify optional (5x or 10x at AF point)
Three AF modes – Live mode/Quick mode/Face Detection
Remote live view using EOS Utility 2.0 (via USB or WiFi/Ethernet using WFT)
On (histogram via INFO button)
Display mode same as last used Play mode
2 / 4 / 8 sec / Hold
|Playback modes||1. Single image with exposure, file number, storage slot
2. As 1 but also image count and quality
3. Detailed exposure information, thumbnail and luminance histogram
4. Less detailed exposure info., thumbnail, luminance and RGB histograms
|Playback features||Optional blinking highlight alert
Optional AF point display
Magnified view (up to 10x)
2×2 or 3×3 thumbnail index
Jump (by 1, 10, 100 images / by screen or date)
Delete / Protect
|Flash||Auto pop-up E-TTL II auto flash
FOV coverage up to 17 mm (27 mm equiv.)
Guide number approx 13 m / 43 ft (ISO 100)
Cycle time approx. 3 sec
Flash compensation +/-2.0 EV in 0.3 or 0.5 EV increments
X-Sync: 1/250 sec
|External flash||E-TTL II auto flash with EX-series Speedlites
In-camera flash configuration (currently only 580 EX II)
Wireless multi-flash support
|Shooting modes||Auto, Creative auto, Program AE (P), Shutter priority AE (Tv), Aperture priority AE (Av), Manual (M), Auto depth-of-field, Portrait, Landscape, Close-up, Sports, Night portrait, Flash off, Camera user settings 1, Camera user settings 2,|
High-speed continuous: 6.3 fps
Low-speed continuous: 3 fps
Self-timer: 2 or 10 sec (3 sec with mirror lock-up)
|Burst buffer||Large/Fine JPEG: 90 frames (with UDMA card)
RAW: 16 frames
|Auto rotation||On (recorded and LCD display)
On (recorded only)
|Custom functions||25 custom functions with 74 settings in 4 groups|
|Menu languages||English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Japanese|
|Portrait grip||Optional WFT-E3/E3A
Optional BP-E2N battery grip
Optional BP-E2 battery grip
|Connectivity||USB 2.0 Hi-Speed
N3 type wired remote control
PC Sync flash terminal
Communication terminal on base for WFT-E3/E3A
|Storage||Compact Flash Type I or II (inc. FAT32)
Supports UDMA cards
Canon Original Data Security Kit supported (“Original Image Data”)
No CF card supplied
|Power||Lithium-Ion BP-511A rechargeable battery (supplied & charger)
Supports BP-511 / BP-511A / BP-512 / BP-514
CR2016 Lithium battery (date/time backup)
Optional AC adapter
|Mounts on base of camera and also acts as vertical grip
Has its own BP-511A battery
Wireless 802.11b / 802.11g
Wireless security: WEP, TKIP/AES, WPA-PSK, WPA2-PSK
Wireless methods: Infrastructure or Ad Hoc
Wired ethernet (100 Base-TX)
Transfer: FTP, PTP (remote control by computer), HTTP (view / remote fire)
USB host capable: External hard drives, flash drives
USB comms: GPS devices (records coordinates and altitude in image header)
|Dimensions||146 x 108 x 74 mm (5.7 x 4.2 x 2.9 in)|
|Weight||No battery: 730 g (1.6 lb)
With battery: 822 g (1.8 lb)
|Canon EOS 50D||Canon EOS 40D|
|Sensor||15.0 million effective pixels||10.1 million effective pixels,|
|Image sizes||4752 x 3168, 3456 x 2304, 2353 x 1568||3888 x 2592, 2816 x 1880, 1936 x 1288|
|RAW files||CR2 format, 14-bit, RAW full resolution, sRAW1 (7.1 MP), sRAW2 (3.8 MP)||CR2 format, 14-bit, RAW full resolution, sRAW (2.5 MP)|
|Image processor||DIGIC IV||DIGIC III|
|Sensitivity||ISO 100 to 3200, extendable to H1 (6400) and H2 (12800).||ISO 100 to 1600, extendable to 3200.|
|Auto ISO||ISO 100 to 1600||ISO 100 to 800|
|Noise reduction||Four levels||On/Off|
|Auto lighting optimizer||Four levels||On/Off|
|AF adjustment||All lenses or up to 20 individual lenses, +/- 20 steps||No|
|Viewfinder info||Now includes Auto Lighting Optimizer icon|
|LCD monitor||3.0 ” TFT LCD, 920,000 dots||3.0 ” TFT LCD, 230,000 dots|
|Live view AF||Quick mode (Phase detect), Live view mode (Contrast detect), Face detect (Contrast detect)||Phase detect|
|Peripheral illumination, correction||Profiles of 26 lenses includes, space provided for 14 extra profiles|
|User modes||Auto, Creative Auto, Program AE (P), Shutter priority AE (Tv), Aperture priority AE (Av), Manual (M), Auto depth-of-field, Portrait, Landscape, Close-up, Sports, Night portrait, Flash off, Camera user settings 1, Camera user settings 2||Auto, Program AE (P), Shutter priority AE (Tv), Aperture priority AE (Av), Manual (M), Auto depth-of-field, Portrait, Landscape, Close-up, Sports, Night portrait, Flash off, Camera user settings 1, Camera user settings 2, Camera user settings 3|
|High-speed continuous||6.3 fps, Up to 60 JPEG Large/Fine images, Up to 90 JPEG Large/Fine images (UDMA)||6.5 fps, Up to 75 JPEG Large/Fine images|
|Menu UI||Digic 4 interface||Same as EOS-1D series|
|Connectors||USB 2.0 Hi-Speed, Video out, Mini HDMI connector, N3 type wired remote control, PC Sync flash terminal, Communication terminal on base for WFT-E3/E3A||USB 2.0 Hi-Speed, Video out, N3 type wired remote control, PC Sync flash terminal, Communication terminal on base for WFT-E3/E3A|
|Weight||No battery: 730 g (1.6 lb), With battery: 822 g (1.8 lb) (measured)||No battery: 740 g (1.6 lb), With battery: 836 g (1.8 lb) (measured)|
|Canon EOS 40D||Canon EOS 30D|
|Weatherproof||Battery door and storage compartment||No|
|Sensor||10.1 million effective pixels
5.7 µm pixel pitch
|8.2 million effective pixels
6.4 µm pixel pitch
|Image sizes||3888 x 2592
2816 x 1880
1936 x 1288
|3504 x 2336
2544 x 1696
1728 x 1152
|RAW files||CR2 format, 14-bit
RAW full resolution
sRAW (2.5 MP)
|CR2 format, 12-bit
RAW full resolution
|Image processor||DIGIC III||DIGIC II|
|Dust reduction||High speed vibration of filter||None|
|Auto focus||9-point TTL CMOS sensor
Points cross-type for F5.6 or faster lens
Center point additionally sensitive with lenses of F2.8 or faster
|9-point TTL CMOS sensor|
|Metering range||0.0 to 20 EV||1.0 to 20 EV|
|Spot metering||Approx. 3.8% at center||Approx. 3.5% at center|
|Auto ISO||ISO 400 to 800 / 100 to 800 depending on exposure mode||ISO 100 to 400|
|White Balance||2500 – 10000 K in 100 K steps||2800 – 10000 K in 100 K steps|
|Viewfinder||95% frame coverage
Eyepoint: 22 mm
|95% frame coverage
Eyepoint: 20 mm
|Focusing screen||Interchangable precision matte
Two other screens available
|Fixed precision matte|
|Viewfinder info||Now includes ISO sensitivity, B&W icon|
|LCD monitor||3.0 ” TFT LCD
|2.5 ” TFT LCD
|LCD Live View||Yes, including mirror-drop AF||No|
|Main LCD settings display||When changing settings such as AF mode or White Balance||No|
|Opening CF door||Warning message shown||Power down, loses images|
|Mirror lock-up||Single or multiple exposures||Single exposures|
|Mirror mechanism||Motor up / down, quieter, faster||Spring up / motor down|
|Playback modes||Exposure line at top in single image view||No exposure in single image view|
|User modes||Three custom user modes on mode dial||No user modes|
|High-speed continuous||6.5 fps
Up to 75 JPEG Large/Fine images
Up to 30 JPEG Large/Fine images
|Portrait grip||WFT-E3/E3A, BP-E2N, BP-E2||BP-E2|
|Wireless connectivity||WFT-E3/E3A Integrates as vertical hand grip||WFT-E1/E1A
|Menu UI||Same as EOS-1D series||Sames previous xxD series|
|AF-ON button||Rear ‘under thumb’||None|
|Rear buttons||Direct print, Menu, Play, Erase, Jump, Info, Picture Style||Direct print, Menu, Info, Jump, Play, Erase|
|Top right buttons||Lamp
Metering / WB
AF / Drive
ISO / Flash comp.
AF / WB
Drive / ISO
Metering / Flash comp.
|Dimensions||146 x 108 x 74 mm(5.7 x 4.2 x 2.9 in)||144 x 106 x 74 mm (5.6 x 4.2 x 2.9 in)|
|Weight||No battery: 740 g (1.6 lb)
With battery: 822 g (1.8 lb)
|No battery: 706 g (1.6 lb)
With battery: 785 g (1.7 lb
Items below are Pre release rumours – retained for archive purposes
25th As expected the ‘leak’ site is now password protected
The sample images have been saved though [FKR]
As you’d expect many people are still crying ‘Fake’ – well done if it is! (I doubt it though ;-)
24th A Japanese site looks to have the announcement info for the 50D on it (note 18-200 lens)
This is the URL www.canon.icp.dog-cr.jp/products/camera/eos/50d/index.html
The page certainly looks like a temporary site, but for my mind has just too much info to be a fake (then again I can’t read Japanese! Correction, it’s in chinese ;-)
Certainly looks to be a well timed spoiler for any Nikon release in the next day or so ;-)
A run through Google’s translation service shows that at 15.1MP it is at 6.3 FPS (150k shutter), has HDMI, 12800 max ISO, a VGA display and Digic IV gets an outing.
There are sample images (see above) on the site too. The 1600 ISO one of the car is very nice.
There is a big screen at the back too.
Liveview and an emphasis on AF
Note the two kit options below
22nd The info below has now appeared on Bob Atkins site, which is as good enough as ‘real’ for many ;-)
1.6x crop – 22.3×14.9mm
15.1MP — 4752 x 3168 pixels
JPEG´s + RAW + sRAW1 (7.1MP) + sRAW2 (3.8MP)
Auto Brightness Processing
95% viewfinder .95 magnification
9 point af (All Cross Type)
AF Fine Tuning [AF microadjustment]
Face recognition for AF
ISO 100-3200 Expanded 6400-12800
Auto ISO 100-1600
LCD VGA type 920,000 3″
6.3 FPS (high speed) 3fps (low speed)
Buffer: 16 RAW – 60 JPG – 10 RAW+JPG
Pop-Up flash (13/43 at ISO 100)
Camera User settings C1 & C2
Battery BP511A – charger CB-5L
Shutter Actuations: 100,000
There were suggestions of ‘in camera’ IS for wide angle lenses [screen grab of translation]. Just remember that whatever you see is translated from the briefly visible Chinese pages, so may have a lot of variability – there is nothing in the specs about the IS, and this is now believed not to be present.
This bit of news appeared whilst I was asleep and now Canon China have pulled all the pages, such as: http://www.canon.com.cn/products /camera/eos/50d/overview.html
As expected, people have started moaning about the specs already…”We don’t need no stinkin face detection” :-)
Anyway, here are the full specs from the translated page.
Notice a few bits are still not quite clear – no trouble to anyone who remembers 1980’s printer manuals
|Canon 50D Specifications|
|Type:||built-in flash AF / automatic exposure single-lens reflex digital cameras|
|Record Media:||Type I or II CF card, UDMA compatible|
|Image Sensor Size:||22.3mm x 14.9mm|
|Lens Compatability:||Canon EF-series (including EF-S series lenses)|
|Lens mount:||Canon EF mount|
|Type:||CMOS Image Sensor|
|Effective Pixels:||15.1 million pixels|
|Dust removal function:||Auto, Manual, dust data|
|Recording format:||Camera File System Design Rule 2.0|
|Image types:||JPEG, RAW (14 bit Canon original) can record RAW + JPEG|
|Image Sizes:||Large: about 15.1 million pixels (4752 x 3168)
Medium: About 8 million pixels (3456 x 2304)
Small: about 3.7 million pixels (2352 x 1568)
RAW: about 15.1 million pixels (4752 x 3168)
RAW1: about 7.1 million pixels (3267 x 2178)
sRAW2: about 3.8 million pixels (2376 x 1584)
|Create / select Folder:||yes|
|Photo style:||Standard, portrait, landscape, neutral, reliable setup, monochrome, User-defined 1-3|
|White Balance:||Auto, the default (Daylight, Shade, Cloudy, Tungsten Lamp, White fluorescent light, flash), user-defined, colour temperature settings (2500-10000 K)|
|Noise Reduction:||Can be applied to long time exposure and high ISO sensitivity shooting|
|Automatic image brightness correction:||Automatic brightness optimization|
|Highlight Tone Priority||yes|
|The amount of light surrounding the lens correction:||yes|
|Coverage||Vertical / horizontal direction about 95%|
|Magnification:||About 0.95 times (-1 m-1, using 50 mm lens on the infinite distance AF)|
|Eye Relief (Eyepoint)||About 22 mm (eyepiece lens from the central -1 m-1)|
|Built-in diopter adjustment:||-3.0 – +1.0 M-1 (dpt)|
|Focusing Screen:||Ef-A equipped with the standard screen, and can replace the screen (2 sold separately)|
|Depth of Field Preview:||yes|
|Type:||TTL auxiliary video coincidence, the phase detection|
|AF Zones:||9 (all cross)|
|Metering range:||EV -0.5 – 18 (23 ° C/73 ° F, ISO 100)|
|Focus modes:||Single AF, AI Servo AF, Artificial Intelligence AF, manual focus (MF)|
|AF-assist light:||By the built-in flash for a short flash|
|AF fine-tuning:||AF can be fine-tuned|
|Metering Modes:||35 Zone TTL full-aperture metering
Evaluation meter (with the focus of any automatic linkage)
Partial metering (the viewfinder about 9 percent of the area)
Spot (viewfinder central area of about 3.8%)
Central focus of the average metering
|Metering range:||EV 1-20 (23 ° C/73 ° F, the use of EF50mm f/1.4 USM lens, ISO 100)|
|Exposure Control:||Programmed auto exposure (automatic, portrait, landscape, Macro, Sports, Night Portrait, Flash off, creativity automatic, procedures), shutter priority automatic exposure, aperture priority auto exposure, depth of field priority auto exposure, manual exposure|
|SO Sensitivity (Recommended exposure index):||automatic settings between ISO 100-1600, 12800 District creative shooting modes: ISO 100 – 3200 (in 1 / 3 increments), Auto, ISO sensitivity can be extended up to ISO 6400 or ISO 12800|
|Exposure compensation:||Manual and automatic exposure bracketing (with manual exposure compensation can be used in combination), Can be set numerical: ± 2 Stage 1 / 3 or 1 / 2 units to adjust|
|Auto exposure lock:||Auto: evaluation of the use of metering single AF mode of the application of coke
Manual: auto exposure lock button
|Type:||Electronically controlled focal plane shutter|
|Shutter Speeds:||1 / 8000 second to 1 / 60 seconds (automatic mode), flash synchronization speed of 1 / 250 second 1 / 8000 to 30 seconds, B|
|Built-in flash:||pop-up, auto-flash|
|Flash:||13/43 (ISO 100, to m / ft unit) flash coverage: 17 mm camera angle. Recharge time about 3 seconds|
|External flash:||EX series of flash (camera can set up some flash function)|
|Flash Metering:||E-TTL II automatic flash|
|Flash Exposure Compensation:||± 2 Stops, 1 / 3 or 1 / 2 units to adjust|
|Flash Exposure lock:||yes|
|Modes:||Single-shoot, high-speed, low speed, delay (10 seconds or two seconds delay)|
|Continuous speed:||High-speed: up to about 6.3 frames / sec.
Low: up to about 3 frames/ sec.
|Buffer||JPEG large / distinctions: about 60 (90)
RAW: about 16 (16)
RAW + JPEG large / distinctions: about 10 (10)
|Focus:||Fast mode (testing phase)
Real-time mode, real-time facial priority mode (contrast detection)
Manual focus (can be enlarged five times / 10 times)
|Metering Mode:||The use of image sensors to evaluate,Spot|
|Metering range:||EV 0 – 20 (23 ° C/73 ° F, the use of EF50mm f/1.4 USM lens, ISO 100)|
|Mute shooting (quiet mode):||yes|
|Type:||TFT colour liquid crystal display (there are seven brightness adjustment)|
|Monitor size and points:||3 inches, about 920,000 points (VGA)|
|Language Interface:||25 (with English)|
|Zoom :||About 1.5 times – 10 times|
|View images method:||Leaflets images, 10 or 100 images, screen, the date, Folder as a unit Jump|
|High-warning:||Flashing of Excessive exposure regions|
|Compatible printer:||PictBridge-compatible printers|
|Print Image:||JPEG and RAW image|
|Print command:||DPOF1.1 compatible version|
|Number of custom functions||25|
|Camera user settings:||C1 and C2 registered|
|Digital||(Hi-Speed USB) For computer communications and direct printing (Hi-Speed USB)|
|Video output terminal:||3.5 mm mini-jack (optional NTSC / PAL)|
|HDMI mini OUT:||C –|
|Docking Systems terminal:||WFT-E3 Used to connect wireless file transfer for WFT-E3|
|Battery:||Battery BP-511A (1) AC adapter AC ACK-E2. With BG-EN2 or BG-E2 grips AA cells can be used. Clock battery CR2016|
|Battery capacity:||50% flash photography:
23 ° C / 73 ° F at about 640, 0 ° C/32 ° F at about 540.
50% flash photography and Live View display:
23 ° C / 73 ° F at about 170, 0 ° C/32 ° F at about 130.
|Size and weight|
|Size||145.5×107.8×73.5 mm / 5.7 x4.2×2.9 inches|
|Weight:||About 730 grams / 25.7 ounces (body only)|
|Temperature range:||0 ° C-40 ° C/32 ° F-104 ° F|
|Working humidity range:||85 percent or less|
21st As we were told, there is a £60 rebate on the 40D running for a month from today (to 21st Sept)
The Nikon D90 is now appearing with 18-200VR lens, as a ‘place holder’ on several dealers’ sites.
20th The Dutch Canon site has announced a new series of workshops for buyers of the 450D, 40D and 5D. Runs until Jan 1st 2009.
Also in an update to the UK rebate scheme, we hear that at the end of the first month, it may turn into a price cut or be continued.
There is also a report [CR] that the 40D is supposedly current until the end of the year.
19th In an interesting slant on the ’50D’ noises we’re hearing, there is also talk of a rebate scheme being offered on the 40D, starting later this week – but only initially running for a month?
How about no new cameras this month and (at least) 2 new ones for Photokina?
Another 50D/’5D2′ thread on DPR says 15MP 50D soon and the 5D replacement for September.
Typo – should be 17-85 below.
18th From Japan we hear of some 50D Specs [Thanks for the info/translation]
Annouced on 26th Aug (Start sellling in late Sept)
15.10 MP 3.0′ VGA monitor, 6.3FPS, 9 point AF, LV, improved dust-removal system(or improved LV as well)
Body only:150000 Yen, With 17 – 65 85 200000 Yen, With 18-200 220000 Yen, 18-200 lens 80000 Yen.
Digic IV will be used in the upcoming IXUS but not on 50D.
17th The 40D makes it to the ‘clearance section’ of the site of a big Australian dealer. [Camera action]
15th Several reports of a Canon sales meeting in Hawaii [DPR] and the 50D out later this month, but the 5D2 for Photokina – 23/9 to 28/9 Last year the 40D and 1Ds3 were both announced on the 20th Aug.
Also: “The 50D is coming, it was shown this week to camera store owners. Canon USA flew them to Hawaii to show it off, as well as the 18-200IS lens…” “15 Megapixel … $1399 body only” [DPR]
That FM thread from a few days ago is still going strong.
14th Why replace the 40D so soon? Could it be a sign of more agressive marketing from Canon after losing top place in Japan for DSLRs (only by a fraction of a percent in the first 6 months of the year (BCN Ranking)) A new Nikon D90 could possibly do with some competition…
12th More news [FM] suggesting that an 18-200 EF-s lens (f3.5 to 5.6 and with IS USM) is to be announced for Photokina. With some suggestions of a 50D to go with it?
Meanwhile on DPR we get a 50D spec…
12.2 Megapixel APS-C sensor
Single Digic III Processor
ISO 100-3200 (High 6400)
6-8 fps depending on grip
3″ High Resolution OLED LCD
Will accept EF and EF-S Lenses
11 point AF
35 Zone metering
Viewfinder: 100 percent coverage .95 magnification
Pop up flash
New Lithium Ion Battery
Weather sealing slightly better than 40D
(there’s a 5d2 as well)
2nd A Swedish photo magazine’s editor suggests there will be a launch the day before photokina (22nd September)
It also adds that Canon is a bit surprised that the 40D doesn’t sell so well against the D300. There is also the suggestion of a 12MP 50D with AF-ON button and a new grip.
However on FM, I noticed (half way down) a suggestion that the 40D was current for the rest of the year.
40D AF performance is not exactly praised by Rob Galbraith in the latest installment of his 1D3 and 1Ds3 AF testing saga, but it is being compared to the 1D3, which is pretty good after all (even with various foibles).
July 31st Tomorrow or Monday? Both suggested dates for Canon’s next announcement (before the Olympics). The other info suggested two cameras – one single digit, and one double digit… Full frame 50D anyone? ;-) This from a reader and regular contributor (thanks) watching various Chinese forums.
25th Lots more reports of price drops for the 40D, although not many I’ve seen in the UK. Is a 50D on the way with a sensor upgrade (12 or 14MP) or is it, as I’ve heard suggested, to make way for a ‘cheap’ FF 7D or 50D.
It seems [CR] that Best Buy may be listing the 40D as EOL in October.
Canon makes hefty margins on lenses and maybe has decided that EF-s is just for entry level. That said, the 40D design is good one, so I’m more inclined to go along with a recent mail we received suggesting we’ll see a replacement with:
1.6x 12-14MP sensor (a new one based on the new CMOS Canon have been touting for some time)
Appreciably better noise performance than the 450D sensor.
Live view with Phase and Contrast AF.
Minor changes in Much improved weather sealing ;-)
July 20th US Rebates end, and the 40D stays at the rebated price on Amazon. Look for more 50D rumours in the coming week…
8th Is a 40D refresh being moved from the expected 18 month cycle (we’ll see it at PMA in 2009) or will new sensor technology make it into the 50D for Photokina [potn]
Whilst I’ve been sent various info on the new sensor developments, the only line that was slated for potentially moving to annual updates was the bottom end of the DSLR range.
17th Quite a bit more chatter about the imminent demise of the 40D, although looking at the release history points to an early 2009 announcement.
The UK price for the 40D is now around the £600 mark with the 450D at £400 and the 5D at £1200, 1D3 at £2400 and 1Ds3 at £4600.
In Canada there are Canon employee discounts on the 40D (such as often given on soon to be replaced stock) [CR]
Far be it for me to suggest that anyone ever manufactures news items for their blogs ;-) :-)
23rd There seems to be renewed levels of interest in a 40D follow-up. Lots of 50D threads [POTN] appearing on the usual forums, but nothing more than the odd wish list as far as I can see ;-)
The 40D is getting significant acclaim and the price has come down noticeably. I still don’t see anything happening in the way of a 50D until early next year. Expected announcements this summer would be something to replace the 5D and maybe that 1000D mentioned in DPP. Some money also seems to be going on a 1DMk3N (better screen and other tweaks) and sneaking up on the rails is that old favourite, the 3D
26th January A 40D update already?
Since Canon have just announced the 12MP 450D and not an update to the venerable 5D, a lot of people are still hoping for something else at PMA next week.
Current favourite on DPR is for a new model, a ‘step up’ from the 40D. Have a ramble through this DPR thread for more… ;-)
Nikon did a quick update with the D40X, so why not an EOS40DN with the improved AF, the 12MP sensor and the contrast detect AF, from the 450D
If you look through previous Canon release strategies you’ll notice that all new stuff tends to get announced on the same day some time Jan/Feb or Aug/Sept
26th December 2007
In yet more “We’ve seen a bar code, so it must be true” news, a Chinese site is mentioning both the 70D and 320D. It also manages to work in some (wrong) info from the Swedish Canon interview (5D2 page) suggesting that the cameras will be part of an announcement on the 24th Jan (there is no actual mention of camera announcements in the original interview – the 24th date could just as well be a stack of copiers and printers ;-) That said, given that PMA is shortly afterwards, many -are- expecting a 5DMk2 and 450D.
Some specific 50D related info was amongst several interesting items we were recently sent. -Currently- it’s key features are:
12mp sensor still at 1.6 crop
In the ‘most wanted’ category (from a marketing POV) are:
Extra AF points (half way to the 1 series)
High resolution screen
Full AF in live view
Still on the ‘maybe’ list are:
16 bit A/D on RAW (possible with DIGIC IV)
Built in WiFi
Hard Drive Grip (80-100GB drive in a dedicated ‘grip’ – possibly solid state memory)
The full AF in live view and ISO 6400 as an H2 option could currently be done in firmware for the 40D, but doing this as a firmware upgrade would reduce the feature list of the 50D, although now there is real competition in the market this could change.
The 50D development is still at early stages rather than say the 5D2 which is pretty much ‘feature complete’ ready for early next year (or sooner if need be)
Interestingly the reaction to the Pro Level AF and metering in the D300, and what appears in a D80X (or whatever) may do more to make the 50D a bigger advance over the 40D than might have been.
The D300 is generally seen as marking a major change in the market. Canon and Nikon have retained their pro-level AF and exposure for their top line bodies, making that (and the extra size, ruggedness etc) a real distinguishing point. The Canon marketing point of view is that this was an inevitable part of competion and the same change is due in the xD series.
12th September 2007 At last a rumour – OK it’s from POTN, but…
“Digic IV, 16mp FF with 10mp crop mode, 3.0 inch higher resolution LCD, MLU button (god, finally!), next-gen dust removal, 45 point AF, ISO 100-6400, boost from 50-12800, 8fps @ 16mp, 11 @ 10mp, face recognitiion, Live View with full AF, bigger viewfinder, proper weather sealing.”
I suspect not, since it would canibalise 5D2 sales or the 16MP FF 3D (the one thats like a digital EOS 1V) ;-)
Will the 50D cure the persistent problems of the 40D – the ones discussed on some forums, from the very day it first shipped :-)
Will it include Digic 4 – will it finally move to a bigger sensor? What about in body IS? Will it be announced for PMA 2009?
I’m sure that this and more will find a home here, over the next couple of years :-)
|Model||Announced||Effective pixels||Auto focus||Continuous (JPEG)||LCD monitor|
|EOS D30||Apr 2000||3.1 mp||3 point||3.0 fps, 3 frames||1.8″|
|EOS D60||Feb 2002||6.3 mp||3 point||3.3 fps, 8 frames||1.8″|
|EOS 10D||Feb 2003||6.3 mp||7 point||3.3 fps, 9 frames||1.8″|
|EOS 20D||Aug 2004||8.2 mp||9 point||5.0 fps, 23 frames||1.8″|
|EOS 30D||Feb 2006||8.2 mp||9 point||5.0 / 3.0 fps, 30 frames||2.5″|
|EOS 40D||Aug 2007||10.1 mp||9 point||6.5 / 3.0 fps, 85 frames||3.0″ (Live view)|
Our most recent info (originally on our 1Ds3 page) about Canon’s plans over the next few years was sent in August (shortly before the 40D was announced)
Sensor technology – Canon have mentioned that full frame sensor chips need two stepper passes. Sony now has the technology to do this in one pass and are preparing their own sensors and selling to them Nikon. However, Canon have a new ‘one pass’ technology too. What’s more, it can do even larger than 35mm (36x24mm) in a single pass.
Canon is very excited about a next generation CMOS sensors they are working on. Two full frame versions have 40M and 50M pixels at the -same- noise level as the current 1D series. Low power supply voltages give cooler chips and lower noise even with smaller pixels. Different circuit fabrication techniques also promise to make close to 100% of the sensor area active pixels. This technology won’t make any of the upcoming models, but is expected in 2009/10.
The competition – Canon were somewhat shocked by the success of the Nikon D80, D40 and D40X. Hence the ‘improved’ 40D and the improved 400D replacement in the works. Canon know what Nikon have coming (D300 and D3) and have planned the 40D, 1Ds III and 1D III as their answers.
However Nikon is moving to CMOS sensors to over the next couple of years. Sony are moving CMOS to a near full frame (1.25 or so) and full (35mm) FF, so Canon is getting serious and starting to plan some aggressive upgrades.
Sony worries Canon somewhat, since with their manufacturing capabilities, they could move the whole price base down for SLRs. So far they haven’t and their lens prices and range are not a worry for Canon. The current Sony Alpha has been less than astounding in the market.
Moreover, Nikon have the camera credibility and certainly won’t stop with the D3 and D300. Their plans for the lower end (D40-D80 as well) are to replace them in much shorter timeframes than their previous 3-4 years. Nikon have moved emphasis from the low end ‘point and shoot’ digital into R&D on the DLSRs. They’ve found this to be 3-4 times as profitable (note Nikon’s record profits over last 12 months). Nikon is more than happy with trouncing Canon for the last 12 months in Japan (not so world wide). So the next 2-3 years will see a major DSLR feature ‘war’.
IS Technology – This is being introduced in some of their consumer grade lenses. The technology has matured to the point that it can be added at only a small price premium. It gives product differentiation – a reaction to Sony and keeps them ahead of Nikon.
Digic IV – Digic III just won’t cut it for the new high density sensors. Digic IV can deal with with the transfer rates for higher bit per pixel images. One Digic IV chip beats the two Digic III in the 1D3.
16 bit RAW – Canon’s target for their next generation of sensors is 16 bits per channel giving true HD quality. They are also looking at processing formats to retain that extra definition.
ISO sensitivity – Canon see their next generation lower voltage CMOS as easily doing ISO6400, with a boost to 12800.
